Precision Cooling
Rittal
Blue e+ IT Wall-Mounted Cooling Unit
Blue e+ IT Wall-Mounted Cooling Unit provides dedicated climate control beside an IT enclosure when overhead placement is unsuitable. The vertical form separates it from roof-mounted and internal rack-cooling products. It serves network rooms and edge installations where the designer must coordinate side clearance, enclosure dimensions, electrical supply, heat rejection, condensate handling, ambient conditions, and the site's monitoring architecture before selecting the configuration.
Product details
Key features
- Speed-regulated components and heat-pipe technology manage cooling demand
- Touch display provides local operating access
- IoT interface supports monitoring and energy data
- Plug-in terminal strip supports electrical connection
Key specs
- Type
- Wall-mounted IT rack cooling bundle
- Useful cooling output
- 3.0 kW
- Voltage
- 110–240 V 1~ or 380–480 V 3~, 50/60 Hz
- Rated output
- 1.05 kW
- Cooling medium
- R-513A refrigerant
- Controller
- e+ controller
- Dimensions
- 450 × 1,600 × 294 mm
- Operating range
- −20 to 60 °C
- Setting range
- 20–50 °C
- Protection category
- IP 24 external; IP 55 internal
