Multi-Circuit Monitors for 100 - 480/277V AC Input Voltage

Multi-Circuit Monitors

BGS16

Models that support up to:
16 full power sensors
12 current-only sensors
100V to 480/277V voltage service
Supports 15A to 4000A split core CTs or Rogowski coil sensors

Multi-Circuit Monitors

BGS32

Models that support up to:
16 full power sensors and 12 current-only sensors
24 full power sensors
32 full power sensors
100V to 480/277V voltage service
Supports 15A to 4000A split core CTs or Rogowski coil sensors

Branch Circuit Monitors

BGS72

Models that support up to:
40 full power sensors
48 full power sensors
56 full power sensors
64 full power sensors
72 full power sensors
100V to 480/277V voltage service
Supports 15A to 4000A split core CTs or Rogowski coil sensors

Multi-Circuit Monitors for 480V AC Delta Input Voltage

Multi-Circuit Monitors

BGS9H

Models that support up to:
3 full power and 6 current-only sensors
6 full power sensors
480V 3-phase Delta voltage service
Supports 15A to 4000A split core CTs or Rogowski coil sensors

Multi-Circuit Monitors

BGS15H

Models that support up to:
3 full power and 12 current-only sensors
6 full power and 6 current-only sensors
9 full power sensors
480V three-phase Delta voltage service
Supports 15A to 4000A split core CTs or Rogowski coil sensors

Multi-Circuit Monitors

BGS18H

Models that support up to:
12 full power sensors
15 full power sensors
18 full power sensors
480V three-phase Delta voltage service
Supports 15A to 4000A split core CTs

Multi-Circuit Monitors

BGS27H

Models that support up to:
21 full power sensors
24 full power sensors
27 full power sensors
480V three-phase Delta voltage service
Supports 15A to 4000A split core CTs
